AMG Alternating Pressure Pad and Pump System
Important Safeguards
Read all instructions before using
Danger -To reduce the risk of electrocution:
- Always unplug this product immediately after using.
- Do not use while bathing.
- Do not place or store product where it can fall or be pulled into a tub or sink.
- Do not place or drop into water or other liquid.
- Do not reach for a product that has fallen into water. Unplug immediately.
Warning – To reduce the risk of burns, electrocution, fire, or injury to persons:
- A product should never be left unattended when plugged in.
- Close supervision is necessary when this product is used by, on, or near children or invalids.
- Use this product only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.
- Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the product to a service center for examination and repair.
- Keep the cord away from heated surfaces.
- Never block the air openings of the product or place it on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep the air openings free of lint, hair, and the like.
- Never drop or insert any object into any opening or hose.
- Connect this product to a properly grounded outlet only.
Save these instructions
Pad system
The air mattress contains 2 sets of air cells which alternately are inflated and deflated every two and half minutes. To minimize movement, full inflation of on set of cells occurs before the large alternate set is deflated. Large cell interlocking support pattern permits high volume of air exchange and maximum vertical excursion between relief and support modes. The electronically welded heavy gauge premium vinyl resists tearing and accidental punctures.
Notes & Instructions for using:
- Place the pump on a flat surface, or suspend the pump on the end of the bed with the attached hooks.
- Place the pad on the top of the bed mattress with the hose connectors near the foot end.
- Connect the air hoses to the pump and pad.
- Check and ensure the air hoses are not kinked or tucked under mattress.
- Plug in the power cord into outlet. Then switch on the pump. The green switch will light when the unit is operating.
- Adjust pressure control. The pump provides maximum effectiveness when two fingers can slide between patient’s buttocks and a deflated pad chamber.
Note, caution and warning statements:
Note: Indicates tips for proper use.Caution: Indicates correct operating or maintenance procedures to prevent damage to equipment or other property.Warnings: Calls attention to a potential danger that requires proper procedure or practices to prevent personal injury.
Cleaning and storage
Unit may be cleaned by occasionally dusting or wiping with a surface germicidal disinfectant solution. Do not immerse. Do not heat or steam autoclave
Before placing the unit in storage
1. Check the power cord and plug for abrasions or excessive wear.2. Plug the unit and check the air flow from the uL1it hose connection port. The air flow should alternate between ports every 2 ½ minutes.3. Check the air hoses for kinks or breaks. Replace if necessary.4. If unit is operating properly, coil the hoses loosely and store with the unit in plastic sheeting to protect against moisture and dust.
Storage
To store, fold the pad as the origin.al method.
Caution
Do not use in the presence of smoking materials or open flame. Air flowing through this pad will support combustion.
Warranty
AMG Medical Inc. covers this pump by a (1) year warranty against defects in materials and workmanship. All other parts and components, including the vinyl pad, are warranted for a period of90 days. This warranty is valid for the original purchaser only. Any alterations, abuse, misuse or accidental damage voids this warranty.AMG reserves the right to replace or repair any part that has become defective.
