Toolbox Mounting InstructionsPlease read these instructions and warnings before installation.
DANGERDo not use this toolbox for the storage or transportation of flammables, explosives, hazardous waste or materials such as gasoline, solvents, gun powder, dynamite, propane tanks, acetylene tanks or cutting torches. This toolbox is only intended and safe for use in storing and transporting small tools and equipment and/or other materials.
WARNING
- If the proper mounting brackets are not used, the toolbox could drop off the vehicle while it is moving and cause personal injury and/or property damage.
- Mounting your toolbox through the top, back, or sides without bottom support will significantly reduce the capacity and possibly the life of the toolbox.
- Prior to any welding or drilling holes in a vehicle frame, check for location of fuel tanks, fuel lines, brake lines, or electrical wires.
- If welding is to be done on a vehicle frame in the mounting of this toolbox, disconnect the cables from the battery to prevent shorting of electrical components on the vehicle.
- Always wear protective eyewear when drilling, welding, or checking the underside of a vehicle.
To properly support your Underbody Toolbox, we recommend the use of bottom support mounting brackets. These brackets should be placed so that each end of the toolbox is supported by the full width of the mounting bracket. To prevent rust, touch-up drilled holes with aerosol paint. To prevent water leaks, apply silicone sealant all around each fastener after installation.
| PART NO. | QTY. | DESCRIPTION |
| 1701005 | One Pair of | 18″ x 18″ Structural Welded Brackets |
| 1701010 | One Pair of | 18″ x 24″ Structural Welded Brackets |
| 1701015 | One Pair of | 24″ x 24″ Structural Welded Brackets |
| 1701005B | One Pair of | 18″ x 18″ Structural Bolted Brackets |
| 1701010B | One Pair of | 18″ x 24″ Structural Bolted Brackets |
| 1701006 | One Pair of | 18″ x 18″Formed Welded Brackets |
| 1701011 | One Pair of | 18″ x 24″ Formed Welded Brackets |
| 1701016 | One Pair of | 24″ x 24″ Formed Welded Brackets |
| 1701006B | One Pair of | 18″ x 18″ Formed Bolted Brackets |
| 1701011B | One Pair of | 18″ x 24″ Formed Bolted Brackets |
| 1701030 | One Pair of | 18″ x 18″ Aluminum Brackets |
| 1701040 | One Pair of | 24″ x 24″ Aluminum Brackets |
| 1701031 | One Pair of | 18″ x 18″ Stainless Brackets |
| 1701041 | One Pair of | 18″ x 24″ Stainless Brackets |
WARRANTY
Buyers Products Co. warrants all truck/trailer hardware manufactured or distributed by it, to be free from defects in material and workmanship for a period of one year from date of shipment. Parts must be properly installed and used under normal conditions. Any product which has been altered, including modification, misuse, accident, or lack of maintenance will not be considered under warranty. Normal wear is excluded. The sole responsibility of Buyers Products Co. under this warranty is limited to repairing or replacing any part or parts which are returned, prepaid, and are found to be defective by Buyers Products Co. Authorization from Buyers Products Co. must be obtained before returning any part. No charges for transportation or labor performed on Buyers’ products will be allowed under this warranty.
3000105 Rev. D
