Fingerprint all-in-one 2.0 Instruction Manual

Fingerprint all-in-one instructions 2.0I. ParametersSize: 86*86*26mmScreen: black-white screenFingerprint identification time: <1.5SFalse reject rate: < 0.01%False accept rate: < 0.0001%Fingerprint count: 500Card count: 500 (non-standard)Code count: 2Door controlled: 1Pass mode: fingerprint/card/code, fingerprint & card, fingerprint & codeLinking mode: OfflineII.OperationsTIPs:

• The “FP” in the article is short for fingerprint.
• The “Bell” in the article means the icon of Bell
• Long press on the Bell icon for 3 seconds and enter a six-digit code (default: 888888) to enter the menu.
• Disconnect the power supply, long-press the reset button, and switch on the power for 3 seconds then reset the menu code.
• Each user number supports three fingerprints and one card.
• The pass mode integrating FP and code uses randomly allocated common codes.
• Combination password must first press the fingerprint and then code or card plus
• Press “Bell” to confirm.
• Press “*” to back or cancel.

Menu operations:

Select a number to enter the corresponding menu.1. User Add① FP AddEnter the user number.If the user number has existed, switch to backup registration.Press “Bell” to confirm .Press on the fingerprint reader with the same finger for successive three times.The registration will end upon a success prompt.Continue to the adding or backup as prompted on the screen.② Card AddEnter the user number.Press “Bell” to confirm and then punch the card.The registration will end upon a success prompt.If the card has already exists, replace it or exit as prompted..2. Common codeThere should be two common code at most.Enter “1”, press “Bell” to confirm, enter a six-digit common codeand press “Bell” again to confirm.There will be a prompt of successful saving.The same operation to register ‘2’3. Opening DelayEnter the delay time (maximum: 255s) and press “Bell” to confirm.4. Time SetEnter the Specific dateas prompted, press “Bell” to confirm and go to the next line,Press“*” to return and save.5. Pass mode① FP/Card/Code② FP&Card③ FP& CodeEnter the corresponding digit and save it.6. Menu CodeEnter a six-digit code and press “Bell” to confirm.There will be a prompt of successful saving.7. User delete① Number DeleteEnter the user number and press “Bell” to confirm② ALL DeletePress “Bell” for four times to confirm.8. InitializePress “Bell” four times to confirm the operation9.LanguagePress“Bell”to confirm to Chinese.III. Wiring (Installation standards according to Standard for mounting of type 86 base)
