fox summit Wi-Fi LED Light Bulb User Guide

Table of Contents

Wi-Fi LED Light BulbFS-LB100Quick Start Guide

What’s in the Box

Wi-Fi LED Light Bulb

Quick Start Guide

Safety Instructions

Be sure your light fixture or lamp is switched OFF before installing the Wi-Fi LED Light Bulb.
Your existing light bulb may be HOT, so allow the bulb to cool down before removing.
Do not put your fingers in the exposed light bulb socket.
Practice safe installation habits while installing your Wi-Fi LED Light Bulb.
Properly dispose of your old light bulb and keep it out of reach of children.

Wi-Fi Operation Warnings

Always check that your smartphone or tablet OS and FS Home App is running the most up-to-date version.
Check that your Wi-Fi router is working properly and operates on 802.11b/g/n 2.4GHz with WPA/WPA2 encryption. The App does not support any other network encryptions.
DO NOT use a 5GHz Wi-Fi network.

Wi-Fi LED Light Bulb Installation and App Setup

Download the FS Home App from the App Store or Google Play.FS HomeApp Store is a service mark of Apple Inc. Google Play and the Google Play logo are trademarks of Google LLC.
Connect your smartphone or tablet to your local 2.4GHz Wi-Fi network Your Smartphone Your Wi-Fi Router
Turn off the power to your light fixture and/or unplug it from its power source before removing the existing light bulb. Your existing light bulb may be HOT, so allow the bulb to cool down before removing.
Screw in the Wi-Fi LED Light Bulb into the light fixture or socket. DoNOT turn on the power to the fixture or socket just yet.
Launch the FS Home App.
Sign up for an account or Login with your email or password.
Go to “Device” and press “+” in the upper right-hand of the screen and follow the on-screen pairing instructions.To Pair New DeviceMake sure your phone is connected to a 2.4GHz Wi-Fi networkWi-Fi NAME••••••••Important: Ensure that the network name or SSID is the desired network you want the devices to use. If it is different from your smartphone’s Wi-Fi settings, your device pairing will be unsuccessful
Enter your Wi-Fi network password.
Scan the device QR-Code/UID with your smartphone or tablet or enter it manually. The QR-Code is located on the Light Bulb itself, as pictured below.
Plug in or power up your light fixture with the Wi-Fi LED Light Bulb.
Press “Pair” in the FS Home App within 10 seconds of turning on power to the light socket.

Important: When pairing is successful, a new device will be added to your Device page. If unsuccessful, repeat Step 7.

Troubleshooting

Pairing Unsuccessfula. Make sure that your smartphone or tablet is connected to the desired Wi-Fi network.b. Make sure that the Wi-Fi network your smartphone or tablet is connected to is a 2.4GHz network, not a 5GHz network. This is only necessary when pairing.c. Make sure that the Wi-Fi signal is strong at the desired installation location.d. Unplug or power down other Wi-Fi devices to minimize wireless interference during setup.e. Double check that you are entering the correct Wi-Fi network password.
Doesn’t work properly | Signal Loss a. Check that your Fox & Summit device location is within Wi-Fi range.b. Depending on your device’s location, using a Wi-Fi range extender may be necessary.c. Check that your Wi-Fi router is working properly. Consult the manufacturer of your Wi-Fi router for more information.For more product help and support visit:www.foxandsummit.com/apps/help-center\

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Please note that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the equipment and receiver. –Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.–Consult the dealer or an experienced radio/TV technician for help.

CE marking on this product represents the product is in compliance with all directives that are applicable to it.

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmentally safe recycling.

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov.
