GoRock Altavoz Trolley GR-TR162 Manual

INSTRUCTION MANUALWIRELESS TROLLEY SPEAKERGO-ROCKModelo: GR-TR162

For you safety and continued enjoyment of this product.Always read the instruction book carefully before using

Dear Customer:We appreciate the trust placed in us when purchasing this Go-Rock® product. Our main effort is to offer excellent items, maintaining the strictest quality controls and complying with all current safety regulations, in order to present a perfect and safe product for domestic use

FEATURES

  • True Wireless Stereo function (TWS).
  • Bluetooth wireless connectivity.
  • Support USB/TF card.
  • FM Radio.
  • AUX-in function.
  • Karaoke Function.
  • 2400mAh Rechargeable Lithium battery.

SPECIFICATION

ACCESSORIES

  • Charging cable * 1PCS
  • Audio cable * 1PCS
  • Manual * 1PCS
  • Remote control * 1PCS
  • 3M. Wired Microphone * 1PCS

CONNECT TO BLUETOOTH DEVICETurn on the speaker unit and the Bluetooth switch on your mobile or other device and search for the speaker model name “GR-TR162”.Pair the device.Once device is paired Bluetooth will automatically connect when unit is turned on subsequently.

TWSTurn of both of units, and switch them into Bluetooth mode. Just press and hold PLAY button of anyone of them. Then a simple beep comes out, so the unit is waiting for TWS pairing.Keep hold Mode for 5-10 seconds, TWS connected beep come out, when TWS connected successfully.Note: TWS function only works under Bluetooth mode. And don’t support when use MIC function.

CONTROL PANEL

BLUETOOTH

Turn on the speaker; It comes into Bluetooth mode directly. After pair the device, it can play the music, Short time Press to Play/Pause, Short press and to Prev and Next.

AUX-INAUX-IN, Using the audio cable into AUX jack, and then press MODE to switch to AUX-IN mode. Under AUX-IN, it could not shift Prev and Next by Bluetooth speaker, but can control by connection device.

USB/TF CARDInsert the USB flash memory or TF card into the USB/TF slot. It will read the MP3 format music automatically. Press to Play/Pause, Short press and   to Prev. and Next。

FM RADIO

Press to search FM channel automatically. This operation will scan all FM stations and Pre-record them to memory. The scan procedure will take several minutes to complete and should not be interrupted. Once complete, you can short press or to move forward or backward.

NOTE: connected the cable into AUX Port can received the FM radio clearly. Because it is the same function as antenna

CHARGING

  • Please use the original charging cable to charge.
  • Connect the charging cable to a 2.0A adapter (Adapter not included).
  • Red LED on when charging.
  • Charging time: 5-6 Horas.

REMOTE CONTROL

  1. Unit ON/OFF.
  2. MODE: Mode shift button. Short press and shift to USB/TF mode once, more to AUX/FM mode & default mode will be Bluetooth mode. Press and hold the Mode button on the host speaker to reactivate the paring process between speakers.
  3. Mute.
  4. Play/Pause.
  5. EQ: Press to exchange the EQ mode.
  6. : Under FM/USB/TF/Bluetooth mode, short press to move to previous channel/track.
  7. : Under FM/USB/TF/Bluetooth mode, short press to move to next channel/track.
  8. Decrease the volume.
  9. Increase the volume.
  10. FL Button: Music can be stored in different folders on USB / TF, you can change the folder by pressing the FL button and the speaker will play the music from that particular folder only.
  11. Lights ON/OFF.
  12. Numeric keyboard.

WARRANTY CONDITIONS

  1. This appliance is covered against any factory defects.
  2. The device is changed for a new one as long as it is within the change period and is returned with all accessories and packaging in good condition.
  3. The guarantee will be valid as long as the appliance is accompanied by your invoice or purchase ticket where the exact device and model, or your warranty card duly completed and sealed, is reflected.
  4. THE APPLIANCE WILL BE EXEMPT FROM WARRANTY WHEN:4.1. The appliance has signs of knocks and/or falls.4.2. The appliance shows signs of misuse.4.3. The appliance has signs of overuse.4.4. The appliance is improperly handled.4.5. No supporting document. (Card, ticket, or invoice).4.6. The appliance has not been used in accordance with the instructions for use.

Under no circumstances will direct change or direct payment be made without first reviewing the device and the causes for which it has failed.

GUIDELINES FOR PROTECTION OF THE ENVIRONMENT

This appliance should not be put in to the domestic garbage at the end of its durability, but must be offered at a central point for there cycling of electric and electronic domestic appliances. This symbol on the appliance, instruction manual and pack again put your attention to this import and tissue.

The materials used in this appliance can be recycled. By recycling of used domestic appliances, you contribute important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection.

ALTAVOZ TROLLEY WIRELESS / WIRELESS SPEAKER TROLLEYModelo/Model: GR-TR162

https://www.thulos.com/es/home/649-Array.html

EAN:Azul/Blue: 8436572768901Rojo/Red: 8436572768918

www.thulos.comTechnical Service:
