Infiland Backlit Keyboard User Guide

Infiland Backlit Keyboard

Product parameters

1. Product size: 247.5X150X6.4mm
2. Product color: Black
3. Battery capacity: 400mA
4. Charging time: 2.5 hours
5. Continuous battery life: 200 hours
6. Standby battery life: 180 days
7. Keyboard backlight working time: 4-5 hours

How to charge the keyboard?

Note: The keyboard cannot be charged with an output voltage exceeding 7V/current 5A.

1. When the keyboard charge indicator starts to flash blue, it reminds that the keyboard needs to be charged.
2. Use the Android USB cable prepared in the box, insert the small end into the charging hole of the keyboard, and insert the larger end into the USB port (USA charger/computer/mobile power supply, etc.) to start charging.
3. When the “Charge” indicator lights up red, it means the keyboard has entered charging state. When the charging is complete, the red light will go out.

How to pair the keyboard with iPad/tablet?

Note: Please fully charge the keyboard before using it for the first time .

1. Turn on the power switch on the keyboard, the “Power” indicator will light up in blue for 3 seconds and then go out.
2. Press the “Connect” button, the Bluetooth indicator starts to flash, indicating that the keyboard is ready for pairing.
3. Turn on the Bluetooth of the tablet, it will automatically search to find the device “Wireless Keyboard” and click to connect.
4. The keyboard bluetooth indicator is off, and the tablet shows that my device is connected. At this time, the keyboard and the tablet are successfully connected.
5. Press Fn + letters A/S/D on the keyboard to select a system suitable for tablet.

Common problems

1. When there is no operation on the keyboard for more than 15 minutes, it will enter the sleep mode.Answer: When you need to use it again, just press any key and wait 3 seconds, the keyboard will automatically restart.
2. When the keyboard is in the normal open state, the Bluetooth of the tablet failed pairing to the keyboard after turning the tablet off and reopening.Answer: (1) The battery of the keyboard may be insufficient, recharge the keyboard for 5 minutes and try again.Answer: (2) You can try to turn off the keyboard and then turn it on again, the keyboard and the tablet are automatically connected.
3. When the keyboard is turned on, it is connected to other devices.Answer: You can try to press “Connect” button to restart Bluetooth and pair again.
4. When the keyboard cannot be charged.Answer: You can try another Android charging cable or charger to charge the keyboard.
