Permatex Anti-Seize Lubricant Technical Data Sheet

Permatex Anti-Seize Lubricant Technical Data Sheet

PRODUCT DESCRIPTION

Permatex Anti-Seize Lubricant is a heavy duty, high temperature lubricant that prevents galling, seizing and corrosion during assembly and assures easier disassembly. Also reduces wear in heavy pressure applications. The product contains a refined blend of aluminum, copper and graphite lubricants that can be used on slow moving parts. Meets or exceed the requirements of Military Specification MilA-907E.

PRODUCT BENEFITS

• Effectively lubricates assemblies exposed to high temperatures and heavy contact pressures
• Suitable for service up to 870°C (1,600°F)
• Reduce corrosion and seizing due to weathering or chemicals
• Permits easy disassembly of parts exposed to heat or corrosive environments
• Brush-top aerosol available

TYPICAL APPLICATIONS

• Spark plug threads
• Exhaust manifold and engine bolts
• Anchor pins on brake assemblies
• U-bolts and spring bolts
• Lubricates and permits easy disassembly of assemblies exposed to high temperatures and heavy contact pressures, such as boiler and oven parts, jet engines, and industrial turbines.
• Hinges, gears, chain, sprockets and rollers

DIRECTIONS FOR USE

1. Clean mating surfaces before application
2. For best results, apply to clean, dry surfaces.
3. Clean surfaces with Permatex Brake & Parts Cleaner.
4. Wire brush any loose surface rust.
5. Apply Anti Seize to the parts that require protection.
6. Reassemble parts using normal torque values.
7. Wipe off excess material.
8. Clean brush on aerosol product to make future applications easier.

For Cleanup

1. Clean parts of excess material with disposable towel.
2. Clean hands with Permatex brand hand cleaners.

PROPERTIES OF MATERIAL

Typical Value

Chemical Type: GreaseAppearance: Silver metallic pasteOdor: Light petroleumSpecific Gravity: 1.13Temperature Range, °C (°F): -60(-51) to 870 (1,600)Viscosity, poise: 1000 – 2000Flash Point: >350°F

GENERAL INFORMATION

This product is not recommended for use in pure oxygen and/or oxygen rich systems and should not be selected for use with chlorine or other strong oxidizing materials. For safe handling information on this product, consult the Material Safety Data Sheet, (MSDS).

Ordering Information

StorageProducts shall be ideally stored in a cool, dry location in unopened containers at a temperature between 8° and 28°C (46° and 82°F) unless otherwise labeled. Optimal storage is at the lower half of this temperature range.

NoteThe data contained herein are furnished for information only and are believed to be reliable. We cannot assume responsibility for the results obtained by others over whose methods we have no control. Permatex, Inc. specifically disclaims all warranties expressed or implied, including warranties of merchantability or fitness for a particular purpose, arising from sale or use of Permatex, Inc. products and disclaims any liability for consequential or incidental damages of any kind, including lost profits.This product may be covered by one or more United States or foreign patents or patent applications.

Toll Free: 87 PERMATEX (877-376-2839)10 Columbus Blvd., Hartford, Connecticut 061066875 Parkland Boulevard, Solon Ohio 44139

Not for product specifications.The technical data contained herein are intended as reference only.Please contact permatex, inc., technical service department for assistance and recommendations for your specific application.Permatex, inc., Hartford square north, 10 Columbus boulevard, Hartford, ct 06106 phone – (1-87permatex)

Permatex is a trademark of Illinois Tool Works, Inc. 2009 Permtex, Inc. All rights reserved.
