PHILIPS Bluetooth Wireless Earphone Sport Waterproof Earphone
Important safety instructions
Hearing Safety
|
DANGER |
|
Be sure to observe the following guidelines when using your headset.
- Listen at reasonable volumes for reasonable periods of time.
- Be careful not to adjust the volume continuously upwards as your hearing adapts.
- Do not turn up the volume so high that you can’t hear what’s around you.
- You should use caution or temporarily discontinue use in potentially hazardous situations.
- Excessive sound pressure from earphones and headphones can cause hearing loss.
- Using headphones with both ears covered while driving is not recommended and may be illegal in some areas while driving.
- For your safety, avoid distractions from music or phone calls while in traffic or other potentially dangerous environments.
General information
To avoid damage or malfunction:
|
CAUTION |
|
About operating and storage temperatures and humidity
- Operate or store in a place where temperature is between -15ºC (5ºF) and 55ºC (131ºF) (up to 90% relative humidity.
- Battery life may be shorter in high or low temperature conditions.
Your Bluetooth in-ear headphones
Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.With this Philips wireless in-ear headphones, you can:
- enjoy convenient wireless handsfree calls;
- enjoy and control wireless music;
- switch between calls and music.
What’s in the box
Philips Bluetooth in-ear headphones SHQ6500
Replaceable rubber ear caps
USB charging cable (for charging only)
Quick start guide
Other devices
A mobile phone or device (e.g. notebook, PDA, Bluetooth adapters, MP3 players etc) which supports Bluetooth and is compatible to the headphones (see ‘Technical data’ Check down below).
Overview of your Bluetooth in-ear headphones
- Volume/Track control button
- LED indicator
- On/off, music/call control button
- Microphone
- Micro USB charging slot
Get started
Charge your headphones
|
NOTE |
|
Connect the supplied USB charging cable to:
- the micro USB charging slot on the headphones and;
- the charger/USB port of a computer. LED turns white during charging and turns off when the headphones is fully charged.
|
TIP |
|
Pair the headphones with your mobile phone
Before you use the headphones with your mobile phone for the first time, pair it with a mobile phone. A successful pairing establishes a unique encrypted link between the headphones and mobile phone. The headphones store the last 4 devices in the memory. If you try to pair more than 4 devices, the earliest paired device is replaced by the new one.
- Make sure that the headphones are fully charged and turned off.
- Press and hold the on/off button until the blue and white LED flashes alternately. The headphones remain in pairing mode for 5 minutes.
- Make sure that the mobile phone is turned on and its Bluetooth feature is activated.
- Pair the headphones with the mobile phone. For detailed information, refer to the user manual of your mobile phone
The following example shows you how to pair the headphones with your mobile phone.
- Activate the Bluetooth feature of your mobile phone, select Philips SHQ6500.
- Enter the headset password “0000” (4 zeros) if prompted. For those mobile phones featuring Bluetooth 3.0 or higher, no need to enter a password.
Use your headphones
- Turn on your mobile phone/Bluetooth device.
- Press and hold the on/off button to turn the headphones on. The blue LED flashes. The headphones are reconnected to the last connected mobile phone/ Bluetooth device automatically. If the last one is not available, the headphones try to reconnect to the second last connected device.
|
TIP |
|
|
NOTE |
|
Manage your calls and music
On/off
|
Task |
Button |
Operation |
| Turn the headphones on. | On/off, music/call control | Press and hold for 2 seconds. |
| Turn the headphones off. | On/off, music/call control | Press and hold for 4 seconds. The white LED is on and fades out. |
Music control
|
Task |
Button |
Operation |
| Play or pause music. | Play or pause music. | Press once. |
| Adjust volume | +/- | Press once. |
| Skip forward | + | Long press. |
| Skip backward | – | Long press. |
Call control
|
Task |
Button |
Operation |
| Pick up/hang up a call. | On/off, music/ call control | Press once.1 beep. |
| Switch caller during a call. | On/off, music/call control | Press twice. 1 beep |
Other headphones indicator status
| Headphones status |
Indicator |
| The headphones are connected to a Bluetooth device, while the headphones in standby mode or while you are listening to music. | The blue LED flashes for every 8 seconds. |
| The headphones are ready for pairing. | The LED flashes blue and white alternately |
| The headphones are on but not connected to a Bluetooth device. | The blue LED flashes quickly.If no connection can be made, the headphones will turn itself off within 5 minutes. |
| Low battery level. | The white LED flashes 3 times for every 10 seconds until it is out of power |
| Battery is fully charged. | White LED is off. |
Technical data
- Music time: 4.5 hours
- Talk time: 4.5 hours
- Standby time: 55 hours
- Normal time for a full charge: 2 hours
- Rechargeable lithium polymer battery (120 mAh)
- Bluetooth 4.1, Bluetooth mono support (Headset Profile – HSP, Hands-Free Profile – HFP), Bluetooth stereo supported (Advanced Audio Distribution Profile– A2DP; Audio Video Remote Control Profile – AVRCP)
- Operating range: Up to 10 meters (33 feet)
- Digital echo & noise reduction
- Auto power off
|
NOTE |
|
Notice
Declaration of conformity
Hereby, Gibson Innovations declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. You can find the Declaration of Conformity on www.p4c.philips. com.
Disposal of your old product and battery
Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
This symbol on a product means that the product is covered by European Directive 2012/19/EU.
This symbol means that the product contains a built-in rechargeable battery covered by European Directive 2013/56/EU which cannot be disposed of with normal household waste.We strongly advise you to take your product to an official collection point or a Philips service centre to have a professional remove the rechargeable battery.Inform yourself about the local separate collection system for electrical and electronic products and rechargeable batteries. Follow local rules and never dispose of the product and rechargeable batteries with normal household waste. \ Correct disposal of old products and rechargeable batteries helps prevent negative consequences for the environment and human health.
Remove the integrated battery
|
NOTE |
|
If there is no collection/recycling system for electronic products in your country, you can protect the environment by removing and recycling the battery before disposing the headphones.
Compliance with EMF
This product complies with all applicable standards and regulations regarding exposure to electromagnetic fields.Environmental informationAll unnecessary packaging has been omitted.We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
Trademarks
BluetoothThe Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Gibson Innovations Limited is under license. Other trademarks and trade names are those of their respective owners.
Frequently asked questions
My Bluetooth headphones do not switch on.The battery level is low. Charge the headphones.
I cannot pair my Bluetooth headphones with a mobile phone.The Bluetooth is disabled. Enable the Bluetooth feature on your mobile phone and turn on the mobile phone before you turn on the headphones.
Pairing does not work.Make sure the headphones are in pairing mode.
- Follow the steps described in this user manual.
- Make sure that the LED light flashes blue and white alternately before you release the call/music button. Do not stop holding the button if you see the blue LED only
The mobile phone cannot find the headphones.
- The headphones may be connected to a previously paired device. Turn off the connected device or move it out of range.
- Pairing may have been reset or the headphones have been previously paired with another device. Pair the headphones with the mobile phone again as described in the user manual.
My Bluetooth headphones are connected to a Bluetooth stereo enabled mobile phone, but music only plays on the mobile phone speaker.Refer to the user manual of your mobile phone. Select to listen to music through the headphones.
The audio quality is poor and crackling noise can be heard.The Bluetooth device is out of range. Reduce the distance between your headphones and Bluetooth device, or remove obstacles between them.
The audio quality is poor when streaming from the mobile phone is very slow, or audio streaming does not work at all.Make sure your mobile phone not only supports (mono) HSP/HFP but also supports A2DP (see ‘Technical data’ Check above).
I hear but cannot control music on my Bluetooth device (e.g. play/pause/skip forward/ backward).Make sure the Bluetooth audio source supports AVRCP (see ‘Technical data’ Check above).
For further support, visit www.philips.com/support.
Copyright © Gibson Innovations Limited 2017. All rights reservedThis product has been manufactured by, and is sold under the responsibility of Gibson Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
