RIUKOE LED Stage Lighting
Operate Function
DMX 512 Function
13 Channel mode
|
Channel |
Function |
|
|
1 |
0-255 |
Level |
|
2 |
0-255 |
Level of fine-tuning |
|
3 |
0-255 |
Vertical |
|
4 |
0-255 |
Vertical of fine-tuning |
|
5 |
0-255 |
Speed |
|
6 |
0-255 |
Dimming |
|
7 |
0-255 |
Strobe |
|
8 |
0-255 |
Red dimming |
|
9 |
0-255 |
Green dimming |
|
10 |
0-255 |
Blue dimming |
|
11 |
0-255 |
White dimming |
|
12 |
0-255 |
Self-propelled |
|
13 |
150-250 |
Reset |
11 Channel mode
|
Channel |
Function |
|
|
1 |
0-255 |
Level |
|
2 |
0-255 |
Level offline-tuning |
|
3 |
0-255 |
Vertical |
|
4 |
0-255 |
Vertical offline-tuning |
|
5 |
0-255 |
Speed |
|
6 |
0-255 |
Dimming |
|
7 |
0-255 |
Strobe |
|
8 |
0-255 |
Red dimming |
|
9 |
0-255 |
Green dimming |
|
10 |
0-255 |
Blue dimming |
|
11 |
0-255 |
White dimming |
- MENU
- UP
- DOWN
- ENTER (Confirm button)
- Display Screen
- FUSE
- POWER IN
- DMX IN
- DMX OUT
- Switch
“rSt” is displayed after the power is plugged in and the switch is opened. The moving head light is resetting. Please do not operate.
The step to start the Auto node:
- .Press “MENU” to find “Au01” or “Au02” ,and press “ENTER”.
- Press “UP” or “DOWN” to select “Au01” or “Au02” ,and press “ENTER”.
The step to start the Sound Auto node:
- .Press “MENU” to find “Snon”, and press “ENTER”.
- Press “UP” or “DOWN” to select ‘Snon”, find press “ENTER”.
