QUICKSTART GUIDE
READ BEFORE USING IMPORTANTIMPORTANTE LEA ANTES DE USAR
Any questions? ¿Preguntas? turtlebeach.com/support Model: Stealth™ 700 Gen 2 for Xbox
IMPORTANTPLEASE MAKE SURE YOUR HEADSETIS UPDATED WITH THE LATEST FIRMWARE.
Connect to the Turtle Beach Audio Hub for Windows or Mac® to update the firmware.Customize your settings with the Turtle Beach Audio Hub mobile app for Android and iOS.
https://es.turtlebeach.com/pages/audio-hub
CONTENTS
HEADSET CONTROLS
HEADSET CONTROLS
SUPERHUMAN HEARING®
Use Superhuman Hearing® Mode to pinpoint quiet audio cues like enemy footsteps and weapon reloads.During gameplay, you can activate and deactivate Superhuman Hearing® by pressing the MODE button once, quickly.
Microphone MuteFlip-up mic to mute. There is an audible tone when the mic is muted or unmuted.
 EQ PRESETS |
CONFIGURACIONES DEL EQ |
| Signature Sound | Sonido personalized |
| Bass Boost | Potenciador de graves |
| Bass + Treble Boost | Potenciador de graves y agudos |
| Vocal Boost | Potenciador de voz |
Custom EQ Presets are available through the Turtle Beach Audio Hub mobile app.
CHARGING
The Stealth™ 700 Gen 2 gives you 20 hours of rechargeable battery life. Make sure to charge it regularly before storing it.
Headset StorageAlways charge your headset before storing it for an extended period of time (greater than 3 months). Never store the unit in temperatures above 113°F/45°C.
SETUP FOR XBOX
For new Xbox console setup instructions, go to:turtlebeach.com/Xboxsetup
PAIRING
BLUETOOTH® SETUP
Your Stealth™ 700 Gen 2 will enter Bluetooth® pairing mode once powered on.If no Bluetooth® connection is made in two minutes, Bluetooth® pairing mode will stop.To put your headset into Bluetooth® pairing mode, follow these steps:
- Hold down Bluetooth® Button until “Bluetooth® Pairing” prompt plays
- Connect to your headphones in your phone or tablet Bluetooth® Settings
|
FUNCTION |
ACTION |
| Play/Pause | Press Once |
| Skip Forward | Press Twice Quickly |
| Fast Forward | Press Twice Quickly and Hold |
| Skip Back | Press Three Times Quickly |
| Rewind | Press Three Times Quickly and Hold |
| Answer Call | Press Once |
| End Call | Press Once |
| Reject Incoming Call | Press and Hold |
| Activate Voice Recognition (if available) | Press and Hold |
LED BEHAVIORS
|
HEADSET LED |
MEANING |
| Solid Green | Headset and Console Paired |
| White Fast-Blinking | Bluetooth® Pairing |
| Solid WhiteStays white for 2 seconds, then goes back to green. | Bluetooth® Paired |
| Breathing Green | (While Charging) Battery Full |
| Double-Blink Green | Not Paired |
| Solid Red | (While Charging) Battery ChargingLED turns off when the battery is fully charged. (if the headset is turned off) |
| Breathing Red | Battery Low |
The MODE Button and Mappable Wheel can be assigned to a new function based on your gaming style. To change thebutton’s assignment, follow these steps:
- Download the Turtle Beach Audio Hub mobile app on your iOS or Android device.
- Enable Bluetooth® on your selected device, and pair with your headset to access the app.
- Swipe to the second settings screen to assign new functions.
- Once selected, your headset will save this configuration.
https://es.turtlebeach.com/pages/audio-hub
Scan this QR code for more information on how to customize your remappable buttons.
SETUP FOR PC USE
SYNCING YOUR HEADSET (XBOX WIRELESS ADAPTER)**Xbox Wireless Adapter not included
Volume is controlled through Windows and the headset. For more information on how to control your volume,visit the Stealth™ 700 Gen 2 Support Page at www.turtlebeach.com/support
SYNCING YOUR HEADSET (BUILT-IN XBOX WIRELESS)
1. On your PC, go to Settings > Devices > Connected Devices.a. Choose Add Bluetooth or another device. Windows search for the headset. Select Everything else.
SURROUND SOUND SETUP (AVAILABLE ONLY ON XBOX)
- Go to Settings > General > Volume & Audio Output
- Set Headset Audio to Windows Sonic for Headphones
For updated setup instructions visit:turtlebeach.com/sonic
Regulatory Compliance Statements for the Stealth™ 700X Gen 2Local Restrictions on 802.11a, 802.11b, 802.11g and 802.11n Radio Usage
Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11g, and 802.11n wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11g, and 802.11n products are designed for use only in specific countries, and are not allowed to be operated in countries other than those of designated use. As a user of these products, you are responsible for ensuring that the products are used only in the countries for which they were intended and for verifying that they are configured with the correct selection of frequency and channel for the country of use. Any deviation from the permissible power and frequency settings for the country of use is an infringement of national law and may be punished as such.
To determine whether you are allowed to use your wireless network device in a specific country, please check to see if the radio type number that is printed on the identification label of your device is listed in the manufacturer’s OEM Regulatory Guidance document at the following URL:http://www.turtlebeach.com/homologation or contact Turtle Beach directly.
Federal Communications Commission (FCC) Compliance NoticesThis section includes the following FCC statements for the Stealth™ 700X Gen 2:
- FCC ID: XGB-TB2780
- RF Radiation Exposure & Hazard Warning
- Unlicensed National Information Infrastructure Bands Operation Statement
- Class B Interference Statement
- Non-Modification Statement
Class B Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
RF Radiation Exposure & Hazard StatementTo ensure compliance with FCC RF exposure requirements, this device must be installed in a location such that the antenna of the device will be greater than 2 cm (0.8 in.) from all persons. Using higher gain antennas and types of antennas not covered under the FCC certification of this product is not allowed. Installers of the radio and end-users of the product must adhere to the installation instructions provided in this manual. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Non-Modification StatementUse only the supplied internal antenna. Unauthorized antennas, modifications, or attachments could damage the Stealth™700X Gen 2 and violate FCC regulations. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Please contact Turtle Beach for a list of approved 2.4 GHz and 5.0 GHz antennas.
Unlicensed National Information Infrastructure (U-NII) Bands Operation StatementWithin the 5.25-5.35 GHz band, U-NII devices will be restricted to indoor operations to reduce any potential for harmful interference to co-channel MSS operations. The U-NII devices shall accept any interference from legal communications and shall not interfere with the legal communications. If interference is caused, the user must stop operating the device immediately and cannot resume operation until the harmful interference is clear. Manufacturers of U-NII devices are responsible for ensuring frequency stability such that emission is maintained within the band of operation under all conditions of normal operation as specified in this user manual.
Dynamic Frequency Selection (DFS)U-NII devices operating in the 5.25-5.35 GHz and 5.47-5.725 GHz bands shall employ a DFS radar detection mechanism to detect the presence of radar systems and to avoid co-channel operation with radar systems in order to reduce the likelihood of interference to radar.The modification of wireless broadband and other transceiver devices to operate on unauthorized frequencies or the disabling of DFS capabilities is a violation of FCC rules and may result in unlawful interference to radio communications services critical to public safety.This product is compliant with the Consumer Product Safety Improvement Act of 2008, Public Law 110-314 (CPSIA)
Canadian ICES Statements IC:3879A-2780 (Stealth™ 700X Gen 2)This device complies with ICES-003 and RSS-247 of Industry Canada. Operation is subject to the following two conditions:
- This device may not cause interference, and
- This device must accept any interference, including interference that may cause undesired operation of the device.
To prevent radio interference to the licensed service (i.e. co-channel Mobile Satellite systems) this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing and not supported by Stealth ™ 700X Gen 2 Models.
RF Radiation Exposure & Hazard StatementTo ensure compliance with RSS-102 RF exposure requirements, this device must be installed in a location such that the antenna of the device will be greater than 2 cm (0.8 in.) away from all persons. Using higher gain antennas and types of antennas not covered under the IC certification of this product is not allowed. Installers of the radio and end-users of the product must adhere to the installation instructions provided in this manual. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Deployment StatementThis product is certified for indoor deployment only in the 5150-5250 MHz band. Do not install or use this product outdoors in that frequency band in Canada.
Operation in the Frequency Bands 5470-5725 – MHz and 5725-5850 – MHzUntil further notice, devices subject to this section shall not be capable of transmitting in the band from 5600-5650 – MHz. This restriction is for the protection of Environment Canada’s weather radars operating in this band. Users are advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
European Union and European Fair Trade Association Regulatory ComplianceThis equipment may be operated in the countries that comprise the member countries of the European Union and the European Fair Trade Association. These countries, listed below, are referred to as The European Community throughout this document:AUSTRIA, BELGIUM, BULGARIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY, GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAKIA, SLOVENIA, SPAIN, SWEDEN, UNITED KINGDOM, ICELAND, LICHTENSTEIN, NORWAY, SWITZERLAND
Declaration of ConformityMarking by this symbol:
indicates compliance with the Essential Requirements of the Radio Equipment Directive (RED) of the European Union (2014/53/EU). This equipment meets the following conformance standards:
Safety: EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013 (T-Mark License),IEC 60950-1: 2005 (2nd Ed.) + Am 1: 2009 + Am 2: 2013 (CB Scheme Certificate),EN 62368-1: 2014 + A11 (T-Mark License),IEC 62368-1: 2014 (CB Scheme Certificate)EN 50332-1: 2013, EN 50332-2: 2013, EN 71-3: 2013Additional licenses issued for specific countries available on request
EMC:EN 55032: 2015, CISPR 32: 2015,EN 301 489-1 V2.1.1 (2017-02), EN 301 489-17 V3.1.1 (2016-11)EN 61000-4-2: 2009, EN 61000-4-3: 2006 + A1: 2008 + A2: 2010, EN 61000-4-8: 2010The products are licensed, as required, for additional country-specific standards for the International Marketplace. Additional issued licenses are available upon request.
Radio: EN 300 328 V2.1.2 (2019-07), EN 301 893 V2.1.1 (2017-05)SAR: EN 62311: 2008
Environmental: RoHS 2015/863 amending Annex II to 2011/65/EU, WEEE 2012/19/EU, REACH 2006/1907/EC, Packaging 94/62/EC, Battery 2006/66/EC, Toys Safety Directive 2009/48/EC
Warning! This is a Class B product. In a domestic environment, this product may cause radio interference, in which case, the user may be required to take appropriate measures.
National Restrictions
Indoor Operation The Stealth™ 700X Gen 2 operates in the 5150 to 5350 MHz frequency band and is restricted to indoor use only!Antenna The Stealth™ 700X Gen 2 has integrated antennas that cannot be replaced.Power Level Control The Stealth™ 700X Gen 2 does not allow for customized power level control.Operating Frequency The operating frequency of the Stealth™ 700X Gen 2 is determined by the host console system. As such, it is important that the host console system is correctly configured to meet the local regulations.
This symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste for recycling, please contact your local authority, or where you purchased your product.
Turtle Beach Europe Ltd is obligated as a producer with a main activity of selling under The Producer Responsibility Obligations (Packaging Waste) Regulations 2007.To fulfill our obligation we are registered with Comply Direct and their Recycling Room. Here you will find advice and information on packaging waste management, recycling symbols, and the waste hierarchy principles of reducing, reuse, and recycle. https://www.complydirect.com/the-recycling-room/Please visit the following URL for a complete copy of the Declaration of Conformity: http://www.turtlebeach.com/homologation
Japanese Compliance Statement5.1 5.15 – 5.35 GHz operationOperation in the 5.15-5.25 and/or 5.25-5.35 GHz bands is restricted to indoor use only.
To access the rating label:
- Remove the left earpad.
- Place the ear cushion back onto the silver ring of your headset. The ear cushion will snap into place.
Not seeing what you’re looking for here?Visit turtlebeach.com/support for the latest Tech Support information.
