Specifications
Hybrid Earphone DesignDriver Units:
2 Balanced Armature Driver (Highs) with Tuned Acoustic Expansion Chamber (T.A.E.C.) 1 Balanced Armature (Mid) 10 mm Amorphous Diamond like Carbon (A.D.L.C.) Plasma Enhanced CVD Diaphragm Dynamic Driver (Mids + Low)
SPL: 115 dB @ 1KTHD: <1%Earphone Impedance: 15.5 OHM @ 1KFrequency Response: 5Hz – 20kHzEarphone connector: Beryllium Copper MMCXAcoustic Chambers: 3D Printed Solid-Body
Accessories
SMOKY SUPER LITZ WIRE CABLE
Silver plated copper Litz wire conductors featuring mixed diameter stranding in medical grade PVC jacket 3.5 mm stereo plug to custom beryllium copper MMCX
Campfire Audio Marshmallow tips (small, medium, large) Silicon Earphone Tips (small, medium, large) + bonus featured earphone tips (various sizes) Earphone Clearing Tool, Campfire Audio Pin Campfire Audio – Sustainable Dyed Cork Zipper Case
Warranty
Solaris 2020 includes a 2 year limited liability product warranty covering defects due to manufacturing and assembly.
For more information visit campfireaudio.com/warranty
Fit Guide
Insert Solaris 2020 into your ear with the cable exiting forward allowing it to wrap easily above and behind your ear. The earphones are `Handed’ and fit either your left or right ear. Each earphone has “Left” or “Right” machined into the top to indicate the side.
Designed and hand assembled in Portland, Oregon USA
Using Globally Sourced Components
SOLARIS
- Stainless Steel Spout
- Custom Beryllium Copper MMCX
- Machined Aluminium Body
- Durable ‘Black Onyx’ PVD Finish
Use Instructions
To remove your earphone cable pull the cable in the direction parallel to the earphone connector. Avoid pulling the cable at an angle, as this can damage the MMCX connectors of the cable and/or the earphones.
Take care not to drop your earphones. Each Campfire Audio earphone holds a sensitive and finely tuned transducer. Sudden shocks or impact to the shell can potentially cause damage or alter the performance of the earphone’s transducer.
Damage to the earphone transducers (drivers) are not covered under the earphone’s warranty protection and are subject to a reasonable fee for repair.
Care Instructions
Take special care to keep the earphone openings clear of debris and wax. Carefully use the clearing tool included with your earphones to remove build up from the earphone. Take extra care not to push any foreign objects into the canal of the earphone openings. Avoid moisture build up on the surface and in the interior of the earphone body.
Opening the body of the earphone will damage the seal of the shell and alter the precision tuning of your earphone. Tampering, opening, or altering the shell will void the warranty of your earphone.
Note that extended listening periods at high listening levels can negatively impact your hearing over time. Please enjoy your earphones responsibly.
Questions or comments? Please contact us: [email protected]
Thank you for purchasing Solaris 2020
Nicely Done.
Visit us atcampfireaudio.com
Campfire audio® names and logos are protected by USA Copyright and trademark and other global copyright protections
IEM-CFA-MSR
