SPECIAL PIE Laser Sensing Target
PRODUCT LIST
J10C * 1Manual * 1Package Box * 1
Power Supply
1. 4pcs Brand new AA battery or mobile power supply
Power on and off
- Power On: press power button for 3 secs to power on.
- You can use it after the boot music ends.
- Follow the voice prompts to start shooting after shoot the START/STOP area in the lower left corner by laser shooting simulator.
- Turn Off: press power button for 3 secs to turn off.
Training Modes Setting
Setting methodShort press the mode button to cycle setting modes, 3 modes in total.Introduction of 3 modesMode 1: Time synchronization, all targets go up simultaneously, each target is limited to max. 99 shots within 99secs.Mode 2: Time synchronization, all targets go up simultaneously, each target can only be shot twice.Mode 3: It is also called smart target system mode. When 3 or more targets are put together (within 50 meters), they will automatically get connected after being turned on, and then set to the mode 3 according to the following steps, each time there will be 2 targets light up and wait to be shot, and so on.
Multi-target Setting( Mode 3) Long press menu button to enter setting mode to set chan(channel), add(address), No(number),NU(total number of target) – Press the switch button to switch and press “+”to add number in current option.Long press menu button to exit after setting.
Remark: Parameters setting, including address and number are only effective in local target .Other data(including channel, address, total number of targets and mode) will synchronize to other targets. Group setting method of the targets
J10C contains 3 channels (groups): 01, 02, 03. If you have multiple targets and want to group them, please do as follows:
- Turn off all the targets in other groups first.
- Randomly find one from the current group of targets and set its group channel to 01, and the other targets will automatically synchronize.
- Then modify the number of each target in the current group one by one, which are 01, 02, 03, and so on.
Sound Settings
- Long press the mute button to switch the mute switch.
- The volume can be adjusted, divided into two levels.Adjustment method: Short press the power button 3 times to adjust the volume to the first level. If you are not satisfied, short press 3 times again to adjust.
- Short press the mute button on the main interface to view the shooting time of each shot.
Short press the mute button on the main interface to view the shooting time of each shot.
Sensitivity Setting
If you find that the receiving laser signal of J10c is not sensitive in use, please adjust the sensitivity level to L in the following steps
- Short press the power button once to adjust the sensitivity.
- The sensitivity is divided into two levels, S and L. The default level is S, and it is more sensitive to receive laser signals after adjusting to L.
Compatible Products
Placement Mode
Security Statement
Pay attention to confirm firearms that is refitted to laser shooting simulator be safe before you can use it.
Warranty Policy
- Within 12 months after the product is received, the fault/defect caused by non-human operation will be provided with free maintenance service.
- After the free warranty period, Special Pie will provide 36 months of chargeable maintenance service for this product.
- Under any circumstance, if the product fails due to improper operation, Special Pie will charge the corresponding maintenance fee.
Contact UsGuangdong Special Pie Technology Co., Ltd.Contact: Shirely XieCell Phone: +86-134 2442 5927Email: [email protected]Web: www.special314.com
