IntelliSHOTePTZ Camera
ePTZ CAMERA WITHAUTOFRAMING TECHNOLOGY
ORDERING INFORMATION
Black999-21100-000 (North America)999-21100-001 (Europe/UK)999-21100-009 (Australia/New Zealand)White999-21100-000W (North America)999-21100-001W (Europe/UK)999-21100-009W (Australia/New Zealand)
OVERVIEW
The IntelliSHOT® professional camera makes video collaboration and streaming classes easy and effortless. Equipped with advanced IntelliFrame™ technology, the IntelliSHOT ePTZ camera is the only auto-framing device that can be adjusted based on the room conditions and user preferences. Vaddio’s IntelliFrametechnology is the culmination of years of research and engineering delivering the most precise and reliable auto framing experience.Other cameras on the market that rely on facial recognition fail with facial coverings or falsely identify objects like posters on the wall as people. IntelliFrame uses a combination of exceptionally sensitive motion detection and complex algorithms to deliver smooth, accurate, and reliable participant framing.AV Integrators can now promise personalized video performance with every installation. Because IntelliFrame is adjusted via the web interface, it can be fine-tuned remotely by support staff.The IntelliSHOT is a great choice for conference rooms as people expect great video when joining their Microsoft Teams Room or Zoom Room. The IntelliSHOT has two built-in beamforming microphones making it a great choice for simplifying audio endpoints in small to mid-size conference rooms.The IntelliSHOT is PoE+ powered and the ethernet network connectivity allows you to manage and control the IntelliSHOT via our web-based user interface.
FEATURES
- Advanced Intelligent Framing algorithms keep your participants in view
- 30x zoom with 70.2-degree field of view
- Simultaneous USB 3.0, HDMI, and H.264 IP Streaming (RTSP or RTMP)
- Two integrated beamforming microphones with built-inAcoustic Echo Cancellation (AEC)
- Balanced audio line in and out
- Customizable auto framing experience
- Free Vaddio Deployment Tool for remote management, updates and more
TECHNICAL SPECIFICATIONS
| CAMERA & IMAGE | Outputs/protocols | IP (H,264), USB 30. HDMI 1.4. Balanced Audio |
| Aspect ratio | IP (1,204) 3Pewent.y. 10.9. 3.2 and 4.3 I HDMI. 10.9 11)38. 10.9 | |
| Resolutions/frame rates | Up to 1080p/30 | |
| Image device | 1/2.5-Type Exmor R CMOS sensor | |
| Pixels | 851 million; (8.57M Total Megapixels) | |
| Lens and Horizontal FOV | 30x zoom. 20x optical zoom + 10x IntelliZoom, 70.2° (Wide End) 3.1° (Tele End) | |
| Min. working distance | 80mm (wide), 800mm (tele) | |
| Min. illumination | 1.6 lux; 100+ lux recommended | |
| Backlight compensation | On/off | |
| Aperture/detail | 16 steps | |
| Focusing system | Auto Focus / Manual Focus Mode / One-push Trigger Mode | |
| Gain | Auto / Manual (0 to 33 dB) | |
| White balance | Auto, ATW, Indoor, Outdoor. One-push, Manual | |
| S/N ratio | More than 50 dB | |
| Power | PoE+ | |
| Remote management | Wireless Remote, web interface via Vaddio Device Controller, Telnet | |
| Enhanced Wide Dynamic Range. | Yes | |
| Spotlight Compensation Mode | Yes | |
| Noise Reduction | Yes | |
| Presets | 16 + Custom Home | |
| Invertible | Yes | |
| .lanual Tilt Range | -20°, +30` | |
| Warranty | 3 years with 1 year Advanced Replacement | |
| oianv | Signal to Noise Ratio | 64,3dB |
| Cardioid Type | Omnidirectional | |
| Frequency Response | Flat | |
| Audio Processing (Internal Mics) | Acoustic Echo Cancellation | |
| Microphone Configuration | 2x Beamforming | |
| PHYSICAL &ENVIRONMENTAL | Weight | 4.25 lbs (1.93 kg) |
| Height | 8.375′ (2127 cm) | |
| Width | 6′ (15.24 cm) | |
| Depth | 4.5′ (11.43 cm) | |
| Operating/storage temperature | OfIC to +40°C (32°F to 104,) | |
| Operating/storage humidity (relative) | 20% to 80% RH. non-condensing |
Specifications are subject to change without notice
WHAT’S IN THE BOX:
- IntelliSHOT ePTZ Camera (black or white)
- On-wall mount and hardware (black or white)
- Cable cover (black or white)
- PoE+ power injector
- Vaddio Wireless Remote
- 3.3 ft (1m) Cat-5e cable
- 6 ft (1.8m) USB 3.0 cable, type A to B
- Quick-Start Guide
