vogels Monitor Mount Static PFD 8522 Installation Guide
PFD 8522Installation Instructions
PFD 8522Parts List
| ITEM | DESCRIPTION / PART NO. | QUANTITY |
 |
3/32″ Allen Wrench 1 700146 | 1 |
 |
Monitor Tilter 1 405397 | 1 |
 |
75/100mm VESA® Adapter Plate 1 105587 | 1 |
 |
10-32 x 3/8″ Phillips Flat Head Screw 1 702281 | 1
(4- peck) |
 |
M4 x 12mm Phillips Pan Head Screw 1 702096 | 1
(4- peck) |
 |
Dog Washer 1 105189 | 1 |
 |
10-32 x 3/8″ FPhMS w/Lock Patch 1 705198 | 1 |
 |
7/32″ Allen Wrench 1 701127 | 1 |
 |
Cable Clip 1 104533 | 1 |
FLEXmount™Installation Instructions
- Desk Clamp
- Thru-Desk
- Wall Mount
- Reverse Wall Mount
- Grommet Hole
- Side Bolt
FLEXmount™Parts List
| ITEM | DESCRIPTION / PART NO. | QUANTITY |
 |
Mount Cup 1 406715 | 1 |
 |
Mount Cup Rubber Sole 1105553 | 1 |
 |
Cable Management 1 105538 | 1 |
 |
Large “L” Bracket 1 701117 | 1 |
 |
Small “L” Bracket 1 701116 | 1 |
 |
Rectangular Spacer 1 701544 | 1 |
 |
3/8-16 x 1″ Flat Socket Cap Screw 1 701124 | 1 |
|
3/8-16 x 7/8″ Flat Socket Cap Screw 1 701799 | 1 |
 |
3/8-16 Nylon Stop Nut 1 701418 | 1 |
 |
3/8-16 x 7/8″ Button Socket Cap Screw 1 701122 | 1 |
 |
3/8-16 x 2-1/2″ Hex Head Bolt 700268 | 1 |
 |
1/2-13 x 3″ Socket Set Screw 1701126 | 1 |
